Amscor Specifications

Amscor Specifications

About Amscor Storage Shelving:

Amscor has been in business since 1974. Amscor is a shelving company that provides the highest quality of steel shelving and storage products. Amscor has sold products to nearly every type of business, organization, government, and individual buyer.

Specifications:

Standard Depths and Widths:
12", 15", 18", 21", 24", 30", 36", 42" and 48"
Shelves can be made as small as:
 9" x 9"
Shelves can be made as big as:
48" x 48"

Uprights:
Traditional roll formed 12 or 14 gauge steel
or
Offset roll formed steel

Standard heights:
Starting from 3’3" to 14'3" with sizes at every twelve inches.
Sides and back are made from 22 gauge, 20 gauge or 18 gauge sheet metal material.

Reinforcing bars:
Manufactured from 12 gauge steel.
Amscor praises themselves by being able to accommodate the needs of customers as well as finding the perfect solution for all shelving needs.


Your Choice of Six Shelf Classes:

Class 0 Class 1

Without Reinforcement, for normal loads

Amscor Specifications

With a 1" x 1" 12 gauge reinforcing angle (rebar) placed into the front flange of the shelf
Amscor Specifications

Class II Class III
With rebars placed into the front and rear flanges of the shelf

Amscor Specifications
With rebars placed into the front and rear shelf flanges, plus a thrid rebar (double notched) across the center of the shelf from front to back
Amscor Specifications
Class IV Class V

With metered rebars placed into all four (4) shelf flanges


Amscor Specifications

With metered rebars placed into all four (4) shelf flanges, plus a fifth rebar (double notched) accress the center of the same shelf from front to back
Amscor Specifications

Order by Phone!
800-326-4403



Amscor's Shelf Load Capacity Chart Makes it Easy!
  Class 0 Class I Class II Class III Class IV Class V
Width x Depth

20
Gauge

18
Gauge
20
Gauge
18
Gauge
20
Gauge
18
Gauge
20
Gauge
18
Gauge
20
Gauge
18
Gauge
20
Gauge
18
Gauge
24 x 9 680 840 830 935 1160 1260 1340 1505 1520 1640 1720 1870
24 x 12 640 800 740 895 1125 1190 1295 1445 1465 1600 1610 1805
24 x 15 600 720 690 805 1084 1105 1230 1335 1405 1550 1535 1710
24 x 18 585 650 650 745 985 1050 1150 1235 1305 1425 1470 1565
24 x 21 550 635 635 690 935 1010 1090 1175 1250 1340 1425 1510
24 x 24 525 605 605 645 885 950 1065 1115 1205 1290 1290 1390
30 x 9 670 810 745 905 1040 1175 1200 1430 1370 1570 1520 1810
30 x 12 600 775 670 830 980 1080 1125 1220 1280 1390 1450 1580
30 x 15 560 720 640 775 960 1025 1080 1145 1220 1305 1390 1505
30 x 18 510 670 605 735 900 965 1030 1090 1200 1265 1345 1435
30 x 21 470 640 585 720 865 910 965 1025 1170 1220 1275 1350
30 x 24 420 620 570 700 835 875 950 1005 1145 1190 1225 1280
30 x 30 400 600 550 685 720 830 840 920 1020 1105 1175 1225
36 x 9 625 695 720 810 1010 1150 1160 1320 1325 1460 1455 1670
36 x 12 575 645 645 720 955 1080 1105 1215 1270 135 1405 1505
36 x 15 510 600 615 680 930 990 1065 1150 1260 1345 1360 1445
36 x 18 485 585 590 650 880 945 1005 1080 1145 1210 1305 1380
36 x 21 445 560 570 620 835 885 950 1020 1090 1140 1235 1305
36 x 24 405 525 550 605 800 845 905 960 1055 1110 1170 1235
36 x 30 390 485 530 570 780 810 865 925 980 1040 1115 1175
36 x 36 345 425 450 525 720 770 815 865 945 990 1040 1105
42 x 9 390 465 505 540 685 735 705 825 750 885 895 1095
42 x 12 380 460 480 525 575 630 615 735 670 810 835 1000
42 x 15 330 430 410 510 545 600 590 705 645 775 785 910
42 x 18 280 400 385 480 510 560 560 670 630 735 725 820
42 x 21 270 375 370 465 480 525 540 625 305 675 700 785
42 x 24 265 350 365 425 445 480 505 600 590 640 665 745
42 x 30 240 325 330 405 425 455 470 535 560 605 630 685
42 x 36 225 385 305 370 400 430 455 500 530 570 585 630
42 x 42 *170 *250 *250 335 325 400 385 450 420 505 525 585
48 x 9 265 330 345 405 495 560 515 625 454 665 675 745
48 x 12 250 320 330 405 470 525 500 560 525 625 645 720
48 x 15 240 305 320 385 445 485 465 540 485 570 620 680
48 x 18 230 285 315 365 425 465 445 500 480 525 595 645
48 x 21 235 280 305 350 415 455 435 490 470 515 570 625
48 x 24 230 270 305 345 400 435 430 480 450 510 560 615
48 x 30 210 250 280 325 380 425 415 465 450 500 525 656
48 x 35 185 235 255 305 340 385 375 440 400 470 480 430
48 x 42 *160 *190 *200 *240 250 300 280 350 300 350 350 400
48 x 48 *140 *160 *170 *220 *210 240 245 265 260 300 300 350
