Borroughs book depository storage systems provide versatile, secure storage for books of all
sizes, from volumes to individual literary works. Borroughs’ book depository design, used by
Harvard University, is an excellent choice when priceless archives need to be protected. Borroughs
book depository shelving will allow for high capacity and high efficiency archival storage.
Borroughs book depository storage
systems feature:
• Post Profile
• Shelf and Shelf Mount
• Carton Backstops
• Powder Coating
• Reclaimed Powder CoatShelf support has a Lance &
Bayonet design, allowing a fast
shelf opening adjustment and
initial installation time reductions.
Borroughs’ exclusive post
design is 30% narrower than
other manufacturers’ posts,
reducing the run length without
sacrificing structural integrity.
This allows for a smaller footprint
in the overall system, or
more useable storage space.
Borroughs’ carton backstop is
quick to install and mechanically
connected to the shelf.
Borroughs book depository storage systems provide versatile, secure storage for books of all
sizes, from volumes to individual literary works. Borroughs’ book depository design, used by
Harvard University, is an excellent choice when priceless archives need to be protected. Borroughs
book depository shelving will allow for high capacity and high efficiency archival storage.
Borroughs book depository storage
systems feature:
• Post Profile
• Shelf and Shelf Mount
• Carton Backstops
• Powder Coating
• Reclaimed Powder Coat
Book Depository Storage Systems
Face Plate and Down-
Aisle Support Tube with
engineered connection to
post.
Low Profile Shelves No
overlapping, shelves slide
straight in.
Guardrail for Mechanical
Guidance System and
shelving protection.
Borroughs Technical
Support team is the
most experienced in the
industry, and expertly
guides each project
from design to install.
Book Depository Frame
is fully welded and consists
of post, horizontal
and diagonal supports. All
components are 14 gauge,
the lower frame includes
welded footplates. Frames
are vertically connected
using a tried and proven
splicing system. Horizontal
units are connected with
face plates for added
structural integrity.
COMPONENTS /SPECIFICATIONS:
NationWide Shelving
866-328-5066
ISO 9001:2008 Certified
ISO 14001:2004 Certified
Posts
12 or 14 gauge steel (as required)
2" wide
32' 8" high
Shelves
18 Gauge reinforced steel
768 pound capacity per shelf
Side Shelf Stops (Shelf Mounts)
14 gauge
Rear Shelf Carton Stops
14 gauge
Row End Protection
Wall Guards
In-Rack Sprinkler Guards
(Protect sprinkler heads)
18 gauge
|
|
