Cotterman is a company that specializes in all different types of ladders and they strive at delivering the lowest cost of ladders as well as providing quality ladders. Cotterman ladders are made in the USA.
Stress-free Access to Shelves in Small Storage Spaces
The smooth rolling upper track fixture and wheels allow for easy movement of the ladder along the track. On the front shelf edge is the upper rolling trolley fixture which is mounted to the straight track. The steps have rough tread for the user to keep their balance. The ladder is made of rugged all-welded steel which features 5” deep by 14” wide steps.
Quick Access, Easy to Use, Easy to Store
The Ladder is positioned at an 80º against the shelf. The bottom wheel has a brake to prevent the ladder from moving when in use. The ladder is designed to be easily stored. The ladder has a tight vertical position against the shelves which allow the user access to the equipment in the aisle. Oak rolling library ladders & single track wooden ladders are available.
Ordering Series 7180 Ladders & Track (Or call NationWide Shelving for ladders specifically designed for your space)
First measure the mounting area for the track, use the chart below. The maximum height is about 5-6 feet above the top height shown.
Single Track-Steel
Model No.
Steps
Base Width
Highest Stand Height
Track Ht. Range
Shipping Weight
Tread
Step Dimensions
7180-5
5
29"
50"
86"-95"
50 lbs.
A5
5" x 14"
7180-6
6
29"
60"
96"-105"
55 lbs.
A5
5" x 14"
7180-7
7
29"
70"
106"-115"
60 lbs.
A5
5" x 14"
7180-8
8
29"
80"
116"-125"
65 lbs.
A5
5" x 14"
7180-9
9
29"
90"
126"-135"
70 lbs.
A5
5" x 14"
7180-10
10
29"
100"
136"-145"
75 lbs.
A5
5" x 14"
7180-11
11
29"
110"
146"-155"
80 lbs.
A5
5" x 14"
Track and Mounting Hardware
# 78 Black Oxide Track in 10' Sections
SD5 Splicing Dowel Necessary for Connection of Track Section
L101 Right End Stop Bracket for Horizontal Shelf Mounting
L102 Left End Stop Bracket for Horizontal Shelf Mounting
L103 Centre Bracket for Horizontal Shelf Mounting
L151 Right End Stop Bracket for Vertical Shelf Mounting
L152 Left End Stop Bracket for Vertical Shelf Mounting
